PRO-LOGâ„¢

Specifications

-20°C to 150°C (302°F)

temperature range

up to 2 million

memory capacity

30 days to multi-year (10 years, battery pack + temperature dependent)

DURATION

0.004°C

resolution

18,000psi - 25,000psi

PRESSURE RATING

1/4″ (3/8″ for perforating guns)

sensor TUBING DIAMETER

Applications

• TCP gun fire and performance verification
• Flow allocation during DST
• Cross flow detection and monitoring, especially during build-ups
• Production and injection profiles for completed wells
• Frac performance observation/gravel pack deployment

Features

• Wireless system with no wellhead of packer penetrations
• Deployable on perforating guns
• Autonomous tools permit tool redundancy at each location
• Duplex communication for data collection from multiple devices

Benefits

• Reservoir profiling below obstructions such as an artificial lift pumps
• Continuous flow profiling throughout operation
• Combinable with FLOW-SURE devices to manage your well
• Deployable beneath permanent packers without failure prone wet-connects
